廢氣處理系統
活性炭的吸附:
活性炭的吸附可分為物理吸附和化學吸附。
物理吸附:
主要發生在活性炭去除液相和氣相中雜質的過程中。活性炭的多孔結構提供了大量的表面積,從而使其非常容易達到吸收收集 雜質的目的。就象磁力一樣,所有的分子之間都具有相互引力。正因?yàn)槿绱?,活性炭孔壁上的大量的分子可以產生強大的引力,從 而達到將介質中的雜質吸引到孔徑中的目的。必須指出的是,這些被吸附的雜質的分子直徑必須是要小于活性炭的孔徑,這樣才可能保證雜質被吸收到孔徑中。這也就是 為什么我們通過不斷地改變原材料和活化條件來創造具有不同的孔徑結構的活性炭,從而適用于各種雜質吸收的應用。
化學吸附:
除了物理吸附之外,化學反應也經常發生在活性炭的表面?;钚蕴坎粌H含碳,而且在其表面含有少量的化學結合、功能團形式的氧和氫,例如羧基、羥基、酚類、內脂類、醌類、醚類等。 這些表面上含有地氧化物或絡合物可以與被吸附的物質發生化學反應,從而與被吸附物質結合聚集到活性炭的表面?;钚蕴康奈秸巧鲜龆N吸附綜合作用的結果。
ADSORPTION OF ACTIVATED CARBON: Adsorption of activated carbon can be divided into physical adsorption and chemical adsorption. Physical adsorption: mainly occurs in the active carbon removal of impurities in the liquid and gas phase of the process. The porous structure of activated carbon provides a large surface area, which makes it very easy to absorb and collect impurities. Just like magnetism, all the molecules are attracted to each other. Because of this, a large number of molecules on the Pore Wall of activated carbon can exert a strong gravitational force, thereby attracting impurities in the medium to the pore size. It is important to note that the molecular diameter of these adsorbed impurities must be smaller than the pore diameter of activated carbon, so that it is possible to ensure that the impurities are absorbed into the pore diameter. This is why we are constantly changing the raw materials and activation conditions to create activated carbons with different Pore structure, thus suitable for various impurity absorption applications. CHEMISORPTION: In addition to physical adsorption, chemical reactions often occur on the surface of activated carbon. Activated Carbon not only contains carbon, but also a small amount of chemical binding, functional group form of oxygen and hydrogen on its surface, such as Carboxyl, hydroxyl, phenol, lipid, quinone, ether, etc. . These surfaces contain ground oxides or complexes that react with the adsorbed material to bind and aggregate to the surface of the activated carbon. The adsorption of activated carbon is the result of the above two kinds of adsorption.
